Product Details:
Payment & Shipping Terms:
|
Features: | Flexible Shape Disc | Body Material: | B62 Bronze |
---|---|---|---|
Size Rating: | NPS 2"-12" | Applications: | Seawater |
Bonnet Seal: | Bolted Bonnet | Rating: | 125Lb~300Lb |
High Light: | Flanged End Wedge Gate Valve,C95800 Wedge Gate Valve,B62 Flanged End Gate Valve |
B62 C95800 Bronze Flanged End Corrosion-resistant Wedge Gate Valve For Seawater
Quick Detail
Gate Valve full port design OS&Y, Outside screw and yoke, bolted bonnet.
Flexible wedge, Fully guided
Choice of solid or split wedge
Renewable seat rings
Forged T-head stem
Rising stem and non-rising handwheel
Flanged or Butt welding ends
Available with BG operator.
ASTM B148 C95800 Corrosion resisting,High Strength, Abrasive resistance.
Application temperature: -196°C+260°C
Standard Applications
Design&Manucture:API6D
Face to Face:ASME B16.10
End Flange:ASME B16.5
Butt Welded D:ASME B16.25
Test&Inespection:API598
Specification:
Size:2-32"
Pressure:150-300lb
Material:C95800,C95400,C83600
Temperature:-196°C+545°C
Service: Sea Water
