IP68 Quarter Turn 220VAC Smart Electric Actuator Self Reset

Large Image : IP68 Quarter Turn 220VAC Smart Electric Actuator Self Reset

Product Details:

Place of Origin:	China
Brand Name:	TEKO
Certification:	CE
Model Number:	TG-R

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Packaging Details:	By maste carton
Delivery Time:	7 days after deposit
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	10000 pcs per month

Contact Now

Detailed Product Description

Surface Treatmanet:	Powder Coating	Rotary Angle:	90°, 270°
Protection Class:	IP68	Conneciton Type:	ISO 5211, Star Square
Torque Range:	70-6000 Nm	Voltage:	220VAC, 24V DC Upon Customer Request
High Light:	Self reset IP68 Smart Electric Actuator , 220VAC Smart Electric Actuator , Intelligent Quarter Turn Electric Actuator

Water Proof IP68 Class Local Remote Control Intelligent Quarter Turn Electric Actuator

TG-R series intelligent quarter turn electric actuator is newly designed and developed for especially small ball & plug valves and damper automation.TG-R series intelligent quarter turn electric actuator are reliable, safe, convenient and other advantages such as compatibility, applistability, practicality and so on. We will design and manufacture products solidly and continue our efforts to create more value for customers.

Features

Torque range:70~6000N.m

Switching time:20~120 S

Ambient temperature:-20℃~+60℃

Control method:Intelligent type, Modulating

Weight:2.8 KGS~30.6 KGS

Protection:IP67, (IP68 optional)

1. Compact design:Small, light and compact design, high torque and various control option will meet your specific requirement.

2. ISO 5211 mounting base:Wide, easy mounting base standard to ISO5211/DIN3337

3. Well sealing:By improveing TG-R series intelligent quarter turn electric actuator concave-convex structure of the shell and cover,and sealing with silicone rubber to provide water proof IP67 and IP68(option).

4. External modulating module:TG-R series intelligent quarter turn electric actuator Increase the space of the module, it will make the module more stable and have a longer service life.

Optional Features

No.	Option scheme
1	Heater
2	Water-proof actuator(IP68,10M,250HR)
3	Potentionmeter unit(1k-10k)
4	Proportion control unit(Control signal 4-20mA DC/1-5V/10V)
5	Local control units (Local control open/stop/close optional switch, local/remote switch)
6	Travel 120°, 180°,270°
7	Direct current motor(24VDC)
8	Electric current position sensor (Output 4-20mA DC)
9	Self-reset when power failure
10	Quick opening(2.8s,5s,10s,15s)
