A216 WCB Carbon Steel Body Flanged End BS 1873 Globe Valve Plug Type Disc 150Lb ~ 2500Lb

Large Image : A216 WCB Carbon Steel Body Flanged End BS 1873 Globe Valve Plug Type Disc 150Lb ~ 2500Lb

Product Details:

Place of Origin:	Made in China
Brand Name:	TEKO
Certification:	CE/PED, API
Model Number:	J41W,J61Y

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	By negotiation
Packaging Details:	By export wooden cases
Delivery Time:	15 working days after deposit
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	350 tons per year

Contact Now

Detailed Product Description

Flange End:	ASME B16.5	Design:	BS 1873
Seat Materail:	Metal-to-metal Seat	Body Material:	Carbon Steel, Stainless Steel
Pressrue Rating:	150LB-1500Lb	Face To Face:	ASME B 16.34
High Light:	bolted bonnet globe valve , gear operated globe valve

A216 WCB Carbon Steel Body Flanged End Globe Valve Plug Type Disc 150Lb~2500Lb

ABOUT API GLOBE VALVES

TEKO Cast Steel Globe Valves offer dependable service as regulating or shut off valves for steam, air, gas, oil, oil vapor and high pressure installations. Bolted bonnet for low to medium pressures, whereas pressure seal bonnet is recommended for the highest class

Delivered in a wide range of carbon and stainless steel material. Additional these valves can be manufactured in non-ferrous alloys such as aluminum bronze etc. They are available in the standard API trims or other as per client specification.

MAUFACTURING RANGE

Size: DN2” o DN24”

Class 150# to Class 2500#

DESIGN FEATURES

RF, RTJ or BW

Bolted or pressure seat bonnet

Integral, welded or threaded seat rings.

DESIGN STANDARDS

Design & manufacture according to BS 1873

Face-to-face according to ASME B16.10

End Connection according to ASME B16.5 (RF & RTJ), ASME B15.25(BW)

Test & Inspection according to API 598
