Two Piece Body Soft Seated Lever Operation Flanged Ball Valve ASME / DIN / JIS Standard

Large Image : Two Piece Body Soft Seated Lever Operation Flanged Ball Valve ASME / DIN / JIS Standard

Product Details:

Place of Origin:	Made in China
Brand Name:	TEKO
Certification:	CE/PED, API
Model Number:	Q41F

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	By negotiation
Packaging Details:	By export wooden cases
Delivery Time:	15 working days after deposit
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 tons per year

Contact Now

Detailed Product Description

Body Material:	WCB, CF8, CF8M, Etc	End:	Flange End
Pressure:	Class 150Lb, 300Lb	Bore:	Full Bore
Seat:	Metal Seated, PTFE Seated	Working Temperature:	-25~-180℃
High Light:	flanged end ball valve , v port ball valve

Flanged End Two Piece Body Soft Seated Lever Operation Ball Valve

TEKO 2-piece flanged ball valve is designed for most industrial applications. With ISO direction mounting pad, it is convenient for mounting pneumatic/electric actuator directly up the valve’s ISO mounting pad.

We offer complete flange connection in ASME/DIN/JIS standard. Size range are from 1/2” to 4”.

PTFE/PFA coating on the surface of valve/body/end /ball/stem for anti-sticky function is also available. This will also be convenient to clean the valve just flush by water. Other extraordinary steel material are also available upon request.

Specification

Body& End caps quality investment casting

Available in stainless steel or carbon steel

With ISO5211 direct mouting pad

Adjustable stem packing

Blow-out proof stem design

100% air tested under water at 80-100 psi

Working pressure: class 150LB/PN16/JIS 10K

Option

PEEK/UPE soft kits

Automation application

PTFE/PFA coating
