2 Inch Double Flanged Butterfly Valve CF8 Disc Triple Eccentric For Power Plant

2 Inch Double Flanged Butterfly Valve CF8 Disc Triple Eccentric For Power Plant
2 Inch Double Flanged Butterfly Valve CF8 Disc Triple Eccentric For Power Plant

Large Image :  2 Inch Double Flanged Butterfly Valve CF8 Disc Triple Eccentric For Power Plant

Product Details:
Place of Origin: Made in China
Brand Name: TEKO
Certification: CE, API
Model Number: D43H
Payment & Shipping Terms:
Minimum Order Quantity: 1 pieces
Price: By negotiation
Packaging Details: Pollywooden cases
Delivery Time: 20 days after deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 tons per year
Contact Now
Detailed Product Description
Working Pressure: Class150-600Lb End Conneciton: Double Flange
Size Rating: 2" To 48" End Standard: ANSi B16.5, ASME B16.47
Body Material: CF8, CF8M, CF3, CF3M Driven By: Lever, Gear, Pneumatic, Electric
High Light:

double offset butterfly valve

,

double eccentric butterfly valve

Double Flanged End CF8 Disc Triple Eccentric Butterfly Valve For Power Plant





Product review



Three eccentric butterfly valves have been widely used in industries like petrochemical, power plant, pulp and paper, chemical plant etc. It occupies high-end market of valves due to inherent advantages of high pressure & temperature, low torque, cost-efficiency, compact design, bi-directional tight shut off and long life cycle.





Features



  • High Performance Patented 3D Eccentric Sealing System.
  • Excellent Isolation Function for Gas and Liquid and Flow Regulating Feature.
  • Long Service Life is Available for Welding-in Stainless Steel or Surfacing Welding Hard Alloy Valves.
  • No Friction, No Wearing and No Jam in Valve Seat When Open-Close Operation.
  • Sealing Ring Easy for Replacing and Regulating.
  • Applicable to Bad Working Conditions like High Temperature, High Performance and Corrosive.
  • Lower Operation Torque and Reliable Torque Turn-off.
  • Reliable Fire Resistance Safe Design.



Drawing & Dimensions

2 Inch Double Flanged Butterfly Valve CF8 Disc Triple Eccentric For Power Plant 0



300Lb



DN L H1 H2 Do
50 150 315 115 160
65 170 325 125 160
80 180 340 135 160
100 190 435 140 280
125 200 475 170 280
150 210 510 220 280
200 230 520 240 250
250 250 625 270 350
300 270 670 320 350
350 290 765 370 400
400 310 840 410 400



Tag:

double eccentric butterfly valve,

triple offset butterfly valve,

double offset butterfly valve
