Product Details:
Payment & Shipping Terms:
|
| Type: | Y Pattern | Design: | API 602 |
|---|---|---|---|
| Fluid: | Water, Oil And Gas | Presssure: | 150LB-1500Lb |
| Face To Face: | ASME B 16.34 | Bonnet: | Bolted Bonnet |
| High Light: | bolted bonnet globe valve,gear operated globe valve |
||
Carbon Steel Y Pattern Shape Bolted Bonnet BS1873 Globe Valve For High Pressure
Design Features:
● Low pressure drop compared to vertical globe valves.
● Excellent resistance to the effects of thermal cycling.
● Low torque stroking
● Quick and easy repair in line.
● Seat integrally Stellited.
● Disc fully guided with Stellited seating and guiding surfaces.
● Tight shutoff.
● Stem expansion/contraction thrust unit for high temperature application (optional).
● Other sizes available on request.
Standard Material
| PART | MATERIAL | ||||
| Body (1)(2) | A 105 or A 216 Gr. WCB | A 182 Gr. F11 oA 217 Gr. WC6r | A 182 Gr. F22 orA 217 Gr. WC9 | A 182 Gr. F91 A 217 C12A |
A 182 Gr. F316 orA 351 Gr. CF8M |
| Bonnet(1)(2) | A 105 or A 216 Gr. WCB | A 182 Gr. F11 A 217 Gr. WC6 | A 182 Gr. F22 orA 217 Gr. WC9 | A 182 Gr. F91 A 217 C12A |
A 182 Gr. F316 orA 351 Gr. CF8M |
| Disc(1)(2) | |||||
| Stem (1)(3) | Gr. 410 | Gr. 616 or Gr. 660 | Gr. 630 or Gr. 660 | ||
| Yoke | Carbon steel | ||||
| Gasket (1) | Soft carbon steel–silver plated or Graphite / SS 316 | ||||
| Gasket retainer | A 182 Gr. F6a Cl. 4 | Gr. 616 or Gr. 660 | Gr. 630 or Gr. 660 | ||
| Packing ring(1) | Graphite | Stainless | |||
| Spacer ring(1) | Gr. 4140 option Ni or Cad plated or SS | ||||
| Packing flange | Carbon steel | Stainless | |||
| Gland | Carbon steel | Stainless | |||
| Gland stud | Gr. B7 | ||||
| Gland nut | Gr. 2H | ||||
| Bonnet retainer | Carbon steel | Alloy Steel | Stainless | ||
| Torque arm | Carbon steel | ||||
| Yoke bolting | Gr. B7 | ||||
| Yoke nut | Manganese bronze or Austenitic Ductile Iron A 439 Gr. D-2C | ||||
| Thrust bearing | Steel | ||||
| Handwheel(1) | Malleable iron or steel | ||||
(1) Other materials available, including Graphite.
(2) Stellited.
(3) Hardened.
Our Service
1. All the valves are 100% hydraulic tested as per standard
2. All the materials are 100% as per PO requested.
3. 100% factory price, because we are direct producer of gate/globe/check valve, ball valve, butterfly valves, and so on.
Market, technical support and after-sale service within 24 hours.
