Ductile Iron GGG40 Wafer Check Valve , Dual Plate Wafer Type Check Valve For Water

Large Image : Ductile Iron GGG40 Wafer Check Valve , Dual Plate Wafer Type Check Valve For Water

Product Details:

Place of Origin:	Made in China
Brand Name:	TEKO
Certification:	CE/PED, API
Model Number:	H46X

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	By negotiation
Packaging Details:	By export wooden cases
Delivery Time:	15 working days after deposit
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	350 tons per year

Contact Now

Detailed Product Description

Workign Pressure:	PN10-PN16	Applications:	Clear Water
Seal Material:	Stellited Or Resilient Seated	Structure:	Dual Plate Check
End Connection:	Between Flanges ANSI B 16.5	Body Material:	GGG40, Dutile Iron
High Light:	wafer type check valve , single disc wafer check valve

API 594 Ductile Iron GGG40 Double Plate Wafer Check Valve For Water Applications

Dual plate check valve with low pressure loss. Spring loaded for clean fluids. Water and other non-particle media. The Valve is shut tight at low pressures and should be mounted in between flanges.

Dual Plate Wafer Check valve PN 10/16		Type: Face to face ISO 5752 series 16
GGG40+NBR PN10/16 - Wafer
Materials	Body	Ductile Iron GGG40 + NBR
	Disc	ASTM A351 CF8
	Shaft	ASTM A276 410
	Spring	AISI 321
Other	Connections	flanges DIN 2501 PN10/16 & ASME B16.5 Class 150
	Temperature range	-10ºC up to +80ºC
	Sealing test	18 bar
	Shell test	24 bar
	Inspection & Tests	API 598
(*) Other materials on request

Key features:

Available in sizes: 2" to 24"
Temperature range: -10°C to 120°C
Pressure rating: PN16
Low cracking pressure
Space saving design

Material List

No.	Name	QTY	Material
1	Rivet	2	Aluminium
2	Label	1	Stainless steel
3	Body	1	GGG40 + NBR
4	Disc	2	ASTM A351 CF8
5	O-ring	3	EPDM
6	Spring	2	Stainless steel 321
7	Shaft	2	ASTM A276 410
8	O-ring	2	EPDM
9	Gasket	4	NBR
10	Hexagonal nuts	4	Carbon steel
